Use this deck beam span calculator to look up AWC DCA 6 beam spacing, compare built-up and glulam beam sizes, and estimate post count for a straight beam run.
Last updated
U.S. deck beam span reference Look up the prescriptive maximum simple-span deck beam spacing from the AWC residential deck guide, then estimate posts for a straight beam run before you lock in footing locations.
Quick deck beam scenarios
Scope
This version is a U.S. residential deck-beam lookup based on AWC DCA 6 tables, not a free-form engineered beam design for floors, roofs, multi-span beams, or concentrated loads.
Maximum beam span
8' - 9"
3-2x10 in Southern Pine No. 2 sawn lumber spans up to 8' - 9" when it supports joists up to 12' in the referenced AWC deck table.
For a straight 16' - 0" beam run with no beam overhang, plan 3 posts creating 2 simple spans of about 8' - 0" each.
Decimal span
8.75 ft
Source table
AWC DCA 6 Table 3A
Beam family
Built-up sawn-lumber deck beam
Supported joist span
12 ft
Planned beam run
16' - 0"
Posts needed
3
Simple spans created
2
Average post spacing
8' - 0"
Straight beam layout estimate Use the post count and average spacing as a first-pass deck beam layout, then confirm post size, footing size, beam overhang, and any local code amendments before building.
Beam size
Max span
Decimal feet
Posts for run
Average spacing
2-2x6
4' - 7"
4.58 ft
5
4' - 0"
2-2x8
5' - 11"
5.92 ft
4
5' - 4"
2-2x10
7' - 1"
7.08 ft
4
5' - 4"
2-2x12
8' - 4"
8.33 ft
3
8' - 0"
3-2x6
5' - 10"
5.83 ft
4
5' - 4"
3-2x8
7' - 6"
7.50 ft
4
5' - 4"
3-2x10
8' - 9"
8.75 ft
3
8' - 0"
3-2x12
10' - 6"
10.50 ft
3
8' - 0"
Supported joist span
Max beam span for selected size
Posts for run
Average spacing
6 ft
12' - 9"
3
8' - 0"
8 ft
11' - 0"
3
8' - 0"
10 ft
9' - 9"
3
8' - 0"
12 ft
8' - 9"
3
8' - 0"
14 ft
8' - 3"
3
8' - 0"
16 ft
7' - 8"
4
5' - 4"
18 ft
7' - 3"
4
5' - 4"
How to use this result
Use for built-up Southern Pine deck beams supporting a single span of joists with or without overhangs.
Based on AWC DCA 6 prescriptive deck-beam tables for a single span of joists with or without overhangs.
Assumes 40 psf live load, 10 psf dead load, wet service conditions, and No. 2 grade where applicable.
Beam depth must be at least the joist depth if joist hangers are used.
Straight beam-run planning assumes evenly spaced posts with no beam overhang and does not size footings or posts.
Beam span calculator guide: AWC deck beam table lookups for simple residential post
A beam span calculator helps you look up the maximum prescriptive simple-span length for a residential deck beam before you decide post spacing, footing layout, and whether a larger built-up beam could remove a support.
What this beam span calculator is actually doing
This is a table lookup, not a free-form engineering solver. The calculator checks the selected beam material and size against the AWC DCA 6 prescriptive deck tables and returns the maximum simple span permitted for the supported joist span you choose.
That makes it useful for early residential deck planning, especially when you are deciding rough post spacing or comparing whether one larger beam size could remove a post. It is not a substitute for an engineered design for floor beams, roof beams, multi-span beams, point loads, or unusual service conditions.
How the table basis works
In the AWC deck guide, beam span depends on the joist span the beam is supporting. That supported joist span acts as a practical loading proxy in the prescriptive deck system, so the beam does not need a separate free-form tributary-width input in the public worksheet.
The result assumes one simple span between posts. If your framing uses continuous beams, unusual cantilevers, multiple beam lines, or loading outside the guide assumptions, the table result stops being a safe standalone answer.
Maximum beam span = table lookup by material family, beam size, and supported joist span
The public worksheet follows the AWC DCA 6 beam-span tables rather than deriving a custom engineered answer from raw section properties.
Supported joist span = joist length carried by the beam in the prescriptive deck layout
In the deck guide, the joist span is the lookup variable that captures the loading effect of the deck framing the beam is carrying.
Worked example
Suppose you are planning a U.S. residential deck with Southern Pine framing, a built-up 3-2x10 beam, and joists that span up to 12 feet. In AWC DCA 6 Table 3A, that combination gives a maximum beam span of 8 feet 9 inches between post supports.
That means the beam can span up to about 8.75 feet as a simple span under the table assumptions. If you want wider post spacing, you would compare the same joist span against the next beam sizes rather than assuming the same member can safely stretch farther.
Using the beam-run planner to estimate post spacing
Many searchers are really asking a post-spacing question, not just a table question. They want to know whether a straight beam line can be covered with three posts, whether a 16-foot deck edge needs one intermediate support or two, or how much the average post spacing changes when they upgrade from a double to a triple beam.
The beam-run planner answers that by taking the selected table row and dividing the total straight beam run into equal simple spans that stay at or below the AWC maximum. It does not redesign the beam. It translates the table row into a practical first-pass layout so you can sketch post locations before you size footings.
Required simple spans = ceiling(total straight beam run / maximum beam span from table)
The planner rounds up because every post-to-post segment must stay at or below the selected AWC beam-span limit.
Required posts = required simple spans + 1
A straight beam line needs one more post than the number of simple spans it creates.
Use the straight beam run, not the total deck perimeter.
Assume no beam overhang when using the planner output as a first-pass post layout.
If the layout looks crowded, compare a larger beam size before you move footings.
How to interpret common deck beam span questions
Searches such as "how far can a 2-2x10 beam span" or "what size beam for a 16 foot deck" are really asking for context around the table row. The answer depends on the species group and, most importantly, the supported joist span. A 3-2x10 beam that supports 12-foot joists can go farther than the same beam carrying 16-foot joists because the tributary deck load is lower.
That is why the comparison tables matter. The size table shows what happens if you move from a 2-2x10 beam to a 3-2x10 or 3-2x12 beam for the same supported joist span, while the joist-span table shows how the beam spacing tightens as the beam carries longer joists. Together they answer the real deck beam size calculator question better than a single raw number.
Longer supported joist span means more load on the beam and therefore shorter allowable post spacing.
Triple built-up beams often buy a meaningful spacing increase when a double beam would force an extra footing.
Glulam options may provide longer spans, but some source rows are still prescriptively capped at 18 feet.
Beam span calculator versus general beam size calculator
A general beam size calculator often asks for tributary width, design loads, bending stress, or deflection criteria. That is useful for engineered framing, floor beams, roof beams, and situations outside simple deck construction. This page owns the deck beam span calculator intent instead. It follows AWC DCA 6 Table 3A and Table 3B so the output stays aligned with prescriptive residential deck framing.
That distinction matters because a prescriptive deck beam span table is intentionally narrower than a structural beam design tool. It gives faster, safer answers for the exact deck scenario it covers, but it should not be stretched into a floor beam calculator, roof beam calculator, or a design for heavy concentrated loads.
What to do after you choose the beam row
After the beam span calculator gives you a spacing target, check the rest of the framing chain in the same order a permit reviewer would. Confirm the joist row first, then confirm the beam row, then size posts and footings for the tributary area that layout creates. A beam row that looks efficient can still force larger footings if you push spans close to the prescriptive maximum.
It is also smart to sketch the framing with beam overhangs, actual post locations, and any stairs or concentrated loads before you dig. Deck stairs, hot tubs, planters, masonry finishes, privacy walls, and roof posts can all push the design outside the simple beam span calculator assumptions even if the beam row itself looks acceptable.
What this result does not cover
This calculator does not design floor beams, roof beams, garage headers, or engineered framing outside the AWC deck-guide scope. It also does not check local snow, seismic, or wind requirements, concentrated loads, connection design, bearing length, or footing adequacy.
Even within deck work, the table assumes the published live and dead loads, wet-service conditions, and the material classes shown in the source guide. If the project differs from those assumptions, the span should be checked against the current code tables or by a qualified engineer.
Frequently asked questions
Is this a general structural beam calculator?
No. This version is a U.S. residential deck beam lookup based on AWC DCA 6. It is useful for prescriptive deck framing checks, but it is not a substitute for engineered beam design for other structural cases.
Why does the calculator ask for joist span instead of tributary width?
Because the AWC deck beam tables are keyed by the supported joist span. In that prescriptive system, joist span is the lookup variable that captures the loading effect of the deck framing the beam is carrying.
Can I use the maximum beam span as my post spacing?
For a simple-span beam under the same table assumptions, yes, it is the post-to-post span reference. You still need to check posts, footings, connections, and any local code requirements before building.
How far can a 2-2x10 deck beam span?
It depends on the supported joist span and the species group. In AWC DCA 6 Table 3A, a Southern Pine 2-2x10 beam spans up to 10 feet 1 inch when it supports 6-foot joists, 8 feet 9 inches when it supports 12-foot joists, and 5 feet 9 inches when it supports 18-foot joists.
How far can a 3-2x10 deck beam span?
Again, it depends on the supported joist span and the material row. For Southern Pine in AWC DCA 6 Table 3A, a 3-2x10 beam spans up to 12 feet 9 inches at a 6-foot supported joist span and 8 feet 9 inches at a 12-foot supported joist span. Mixed-species rows are shorter.
How do I estimate how many posts I need?
Use the straight beam run and divide it by the maximum beam span from the selected row, then round up to the next whole number of simple spans. Add one more support to convert spans into posts. For example, an 18-foot beam run with an 8-foot 9-inch allowable span needs three simple spans and four posts if you want even spacing with no beam overhang.
Does this beam span calculator size footings too?
No. It only handles the beam-span lookup and a simple post-layout estimate. Footing size depends on tributary area, soil bearing assumptions, post layout, and local requirements, so footing design has to be checked separately.
Is this a floor beam calculator or roof beam calculator?
No. This page is intentionally narrower than a general beam size calculator. It is for prescriptive U.S. residential deck beams under the AWC DCA 6 assumptions, not for interior floor beams, roof beams, garage headers, or engineered LVL/steel design.
Why does the beam span depend on joist span?
Because the AWC deck beam tables use supported joist span as the loading variable. Longer joists mean the beam carries more tributary deck area, so the beam's allowable post-to-post span becomes shorter.
Can I use a glulam row to get fewer posts?
Sometimes, yes. Glulam rows can provide longer allowable spacing than built-up sawn lumber, which may reduce the number of posts for the same deck beam run. You still need to confirm footing design, treatment suitability, and any local code requirements, and remember that some prescriptive glulam rows stop at 18 feet.
Why do some glulam options stop at 18 feet exactly?
In the source table, some glulam entries are prescriptively capped at 18 feet for footing design. That cap does not automatically mean the beam has reached its absolute engineered limit; it means the prescriptive table stops there.
Can I use the same table for a covered porch or a deck with a hot tub?
Not safely as a standalone answer. Roof loads, hot tubs, masonry finishes, and other concentrated or unusually heavy loads can push the design outside the prescriptive deck beam table assumptions and need a more complete structural check.
