Capacitance calculator Solve capacitance from stored charge and voltage, plate geometry, or capacitive reactance at a chosen frequency. This capacitance calculator also works as a parallel plate capacitance calculator and a capacitive reactance calculator when you need the same result from different electrical inputs.
Mode
Solve C = Q / V when you know stored charge and the capacitor voltage.
Pick the solve mode that matches your search intent: capacitance from charge and voltage, capacitance from plate geometry, or capacitance from frequency and reactance.
Try an example
Scope
Use this to solve common capacitor problems from charge, geometry, or AC reactance without manual back-substitution.
Higher voltage has a squared effect on stored energy, while plate geometry follows the ideal parallel-plate relation and reactance falls as frequency rises.
Check the inputs Enter both charge and voltage to solve capacitance.
Capacitance calculator: solve from charge, plate geometry, or reactance
A capacitance calculator helps when the unknown is the capacitor value itself rather than charge, energy, or voltage alone. This page also explains the main assumptions behind the capacitance calculator result, highlights the supporting figures shown by the calculator, and helps the reader use the estimate without overstating what a quick online tool can prove.
What this capacitance calculator covers
This page solves capacitance in three common ways: from charge and voltage, from plate area and separation with a stated dielectric constant, and from capacitive reactance at a chosen frequency.
That combination makes it useful for bench checks, component planning, and first-pass physical intuition when you need the capacitance value in a readable unit rather than a raw decimal in farads. The calculator reports the result in farads and also scales it into more readable units such as mF, µF, nF, and pF so the number stays usable at the bench or in a design note.
Charge and voltage mode uses C = Q / V
When stored charge and voltage are known, capacitance is the charge per volt. This is often the cleanest way to back-solve capacitance from a stated operating point.
The calculator also reports supporting charge and energy context so the solved capacitance can be interpreted as part of a real storage problem rather than as an isolated number. That makes charge-voltage searches useful when the question sounds like a c q v calculator, a charge and voltage capacitance calculator, or a quick stored-energy check.
C = Q / V
Charge divided by voltage gives the capacitance that would store that charge at that potential difference.
E = 1/2 × C × V²
Stored energy helps translate the solved capacitance into a practical circuit consequence.
Plate geometry mode keeps the physics visible
Parallel-plate capacitance rises with plate area and dielectric constant, and falls as the separation grows. That is why wider plates, thinner gaps, and higher-permittivity materials all push capacitance upward.
The geometry mode is best used as a planning estimate. Real layouts can deviate from the ideal plate model because of fringing fields, tolerances, temperature effects, and dielectric construction details. That is why searches for a parallel plate capacitance calculator usually end up needing both the formula and a plain-language explanation of what the ideal result does and does not include.
C = εr × ε0 × A / d
Relative permittivity, permittivity of free space, plate area, and separation define the ideal parallel-plate capacitance.
Reactance mode ties capacitance to frequency response
Capacitive reactance falls as frequency rises, which is why the same capacitor can behave almost open-circuit at low frequency yet pass higher-frequency content much more easily.
Solving capacitance from reactance is useful when a target impedance is specified at a frequency rather than when a nominal capacitor value is given directly. It is the mode that best matches a capacitive reactance calculator search or a simple capacitor impedance calculator check.
Xc = 1 / (2πfC)
Reactance, frequency, and capacitance are linked reciprocally, so any two let you solve the third.
C = 1 / (2πfXc)
This rearranged form is what the calculator uses when the frequency and reactance are known.
How to choose the right solve mode and read the units
If you know charge and voltage, choose charge-voltage mode. If you know the plate area, separation, and dielectric constant, choose plate geometry mode. If the question is framed as frequency and reactance, choose frequency-reactance mode.
The result can be expressed in farads or in scaled units such as millifarads, microfarads, nanofarads, and picofarads. That unit ladder matters because real capacitor values often look very different depending on whether you are discussing bulk storage, coupling, filtering, or radio-frequency response.
A capacitance calculator is most helpful when it keeps the unit conversion visible instead of hiding the answer behind scientific notation. That way the number is easier to compare against a part marking, datasheet, or design target.
Charge and voltage mode: use C = Q / V
Plate geometry mode: use C = εr × ε0 × A / d
Reactance mode: use C = 1 / (2πfXc)
Using dielectric shortcuts and the reactance sweep
Plate-geometry searches often need a quick dielectric assumption before a full materials datasheet is available. The shortcut buttons for air, FR-4, glass, and a generic ceramic value make it easier to compare how relative permittivity changes the ideal capacitance without retyping common values.
Every solved capacitance also shows a small reactance sweep at common reference frequencies. That turns a static capacitance answer into a first-pass AC check, so you can see whether the same capacitor looks like a large impedance at power-line frequency but a much smaller impedance at audio, switching, or RF-adjacent frequencies.
Worked examples
Example 1: 23.5 mC at 5 V gives 4.7 mF because 23.5 mC divided by 5 V equals 0.0047 F. The same operating point also stores 117.5 mJ at 5 V and 0.0235 C of charge, which helps show why the answer matters in a real circuit.
Example 2: a 1,000 mm² plate area, 1 mm gap, and FR-4 dielectric constant of 4.4 gives about 38.96 pF. That is a realistic scale for a small geometry estimate, but the exact value can shift once fringing and construction tolerances are included.
Example 3: 1 kHz and 1 kΩ give 159.154943 nF. This is a useful check when the question is really about capacitive reactance at a frequency rather than a physical capacitor marking.
A real capacitor is affected by more than the ideal equations. ESR, leakage, dielectric absorption, temperature drift, voltage rating, and construction details all affect how the part behaves once it is installed in a circuit.
That means the calculator result is best treated as a planning estimate or a sanity check. If the design is safety-critical, high-voltage, high-frequency, or pulse-heavy, the datasheet and the actual circuit context still matter more than the ideal number alone.
The same caution applies to parallel-plate results. The ideal layout model is excellent for understanding how area and separation trade off, but it does not model fringing fields, breakdown margin, or non-ideal dielectric behaviour.
What this calculator does not model
This calculator uses the ideal parallel-plate approximation. It does not model fringing fields, edge effects, dielectric losses, ESR, breakdown behaviour, temperature drift, or manufacturing tolerances.
Use it as a sizing and educational reference. If the design is sensitive to field shaping, high-voltage limits, or construction details, move to the analysis method that captures those effects explicitly.
Frequently asked questions
Why does a larger plate area increase capacitance?
Because more overlapping plate area supports more stored electric field for the same separation and dielectric. In the ideal plate formula, capacitance is directly proportional to area.
Why does a smaller gap increase capacitance?
Because the electric field spans a shorter distance, so the same geometry stores more charge per volt. In the ideal plate model, capacitance is inversely proportional to separation.
Is capacitive reactance the same as resistance?
No. Reactance is frequency-dependent opposition from the capacitor, while resistance is a dissipative effect. This calculator uses reactance only to infer capacitance at the stated frequency.
What is capacitance in simple terms?
Capacitance is the ability of a device or geometry to store electric charge per unit voltage. Higher capacitance means more charge can be held at the same voltage.
Which mode should I choose in this capacitance calculator?
Use charge-voltage mode when Q and V are known, plate-geometry mode when area, separation, and dielectric constant are known, and frequency-reactance mode when the question is framed around AC impedance.
How do farads compare with microfarads, nanofarads, and picofarads?
They are all capacitance units. Microfarads, nanofarads, and picofarads are scaled versions of the farad that make practical capacitor values easier to read. The calculator converts into the most readable unit automatically.
Why does the result change with frequency in reactance mode?
Because capacitive reactance is inversely proportional to frequency. As frequency rises, the capacitor charges and discharges faster, so its reactance falls.
Can I use this for supercapacitors or capacitor banks?
Yes as a first-pass estimate. The formulas still apply, but large storage systems also need voltage rating, ESR, leakage, balancing, and safety checks that go beyond the ideal calculation.
Is capacitance the same as capacitor energy?
No. Capacitance describes how much charge a capacitor can store per volt, while capacitor energy describes how much energy is stored at a given voltage. They are related but not identical.
Does a higher dielectric constant always mean a better capacitor?
Not always. A higher dielectric constant can increase capacitance, but other factors like losses, voltage rating, temperature stability, and physical size also matter.
Can I use this as a capacitor calculator for AC circuits?
Use the reactance mode for a first-pass AC check, but remember that real AC analysis can also involve impedance, phase angle, ESR, and the rest of the circuit.
